PC Banner new electric dirt bike HP131E

Draconis Electric Quad ATV 500W 800W Brushless Shaft Draft 4 Wheelers

Draconis Electric Quad ATV 500W 800W Brushless Shaft Draft 4 Wheelers

Short Description:

Model ATV016E, also named Draconis Electric Quad ATV, is available in 500W and 800W high-efficiency brushless motor options with professional shaft drive system. Adopting advanced shaft drive structure instead of traditional chain drive, it delivers smoother power transmission, lower noise, fewer failures and almost maintenance-free performance. This sturdy 4-wheeler electric ATV features stable body structure and reliable handling performance, perfectly designed for kids’ outdoor entertainment, backyard leisure and park light off-road riding. With premium configuration and outstanding durability, it is a trendy and cost-effective bulk wholesale option for global electric ATV retailers and distributors.

  • MODEL: ATV016E
  • Description

    Specifications

    Product Tags

    Details

    细节 (2)
    细节 (3)
    细节 (4)
    细节 (1)

  • Previous:
  • Next:

  • MODEL ATV016E
    MOTOR BLDC BRUSHLESS
    RATED MOTOR POWER 500W 36V
    (800W 48V OPTIONAL)
    MAX POWER 1200W
    MAX SPEED 33KM/H
    THREE SPEED KEY SWITCH AVAILABLE
    BATTERY 36V12AH LEAD-ACID
    HEADLIGHT LED
    TRANSMISSION SHAFT DRIVE WITH DIFFERENTIAL
    FRONT SHOCK SPRING DAMPING
    REAR SHOCK SPRING DAMPING
    FRONT BRAKE /
    REAR BRAKE DUAL-CALIPER HYDRAULIC DISC BRAKE
    FRONT & REAR WHEEL 145/70-6
    (16X8.0-7 OPTIONAL)
    WHEELBASE 805 MM
    SEAT HEIGHT 585 MM
    GROUND CLEARANCE 90MM
    NET WEIGHT 66.5 KG
    GROSS WEIGHT 78 KG
    MAX LOADING 75 KG
    OVERALL SIZE 1180*745*830MM
    PACKAGE SIZE 1160*670*580MM
    CONTAINER LOADING 64PCS/20FT, 136PCS/40HQ
    COLOR RED/BLUE/GREEN/ORANGE/PINK/YELLOW/BLACK
